Leírás és Paraméterek
? Complies with IEEE802.3af/at Standard;
? Support RJ45 Auto-MDI/MDIX
? Supports PoE Power up to 32W for each PoE port
? Auto detect power device
? Remote power and Data feeding up to 100m
? Flow Control for Full Duplex operation and back pressure for Half Duplex Operation
? Support Energy-Efficient Ethernet function (IEEE802.3az)
| Model | GS2008PS2 | ||||||||
| PoE standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, | ||||||||
| IEEE 802.3x, IEEE 802.1X, IEEE 802.1q, IEEE802.1p, | |||||||||
| IEEE 802.1d, IEEE 802.1w, IEEE 802.3ad,IEEE802.3af, IEEE802.3at | |||||||||
| Interface | 8*10/100/1000Mbps RJ45 Port (Auto Negotiation/Auto MDI/MDIX) | ||||||||
| 2* 1000Mbps SFP Slots | |||||||||
| 1 Console Port | |||||||||
| Indicator | PWR, LNK/ACT, PoE | ||||||||
| PoE port | 1~8 port | ||||||||
| PoE Power Budget | 120W | ||||||||
| Power supply | 140W | ||||||||
| PoE Power on RJ45 | Mode A 1/2(+), 3/6(-) | ||||||||
| PoE Power Output | Voltage:55V Power:32W(MAX) | ||||||||
| Indicator | PWR, LNK/ACT, PoE,Speed | ||||||||
| Network media | 10BASE-T: UTP category 3, 4, 5 cable(≤100m) | ||||||||
| 100BASE-TX: UTP category 5, 5e cable(≤100m) | |||||||||
| 1000BASE-T: UTP category 5e, 5 cable(≤100m) | |||||||||
| 1000BASE-X: MMF, SMF | |||||||||
| MAC Address Table | 8K, Auto-learning, Auto-aging | ||||||||
| Jumbo Frame | 9216Bytes | ||||||||
| Transfer Mode | Store-and-forward | ||||||||
| Packet Forward Speed | 14.88Mpps | ||||||||
| Switching Capacity | 20Gbps | ||||||||
| Dimensions(L*W*H) | 280*180*45mm | ||||||||
| Fan Quantity | 1 | ||||||||
| Input Power Supply | 100~240V AC, 50/60Hz | ||||||||
| Operating Temperature | 0°C ~ 40 °C | ||||||||
| Storage Temperature | -40 °C ~ 70 °C | ||||||||
| Operating Humidity | 10% ~ 90% non-condensing | ||||||||
| Storage Humidity | 5% ~ 90% non-condensing | ||||||||
| Surge Protection | ±4KV | ||||||||
| MTBF | >50000 hour | ||||||||
| Electrostatic standard | Contact 6KV, air 8KV | ||||||||
| Certification | CE, FCC ClassA | ||||||||
| green energy saving | Support IEEE(802.3az) | ||||||||
| Gyártó | CUDY |
| Menedzselhető | Van |
| Menedzselhetőség | Web |
| PoE (Power over Ethernet) | Van |
| Port típusa | 1Gb Réz |
| Portok száma | 8 |
| Rack-be szerelhető | Nincs |
| SFP port | 2 |
| Switch típus | Fixed port |
| Switching kapacitás | 20 |
