Leírás és Paraméterek
10/100/1000 Base-T (RJ45) ports
24
100/1000 Base-X (SFP) ports
4
Performance
Switching matrix
56 Gbps
Data transfer rate
42 Mpps
Packet Buffer
1,5 MB
JUMBO Frame
12 K
Number of VLANs
4 K
MAC address table
16 K
Multi-broadcast support
4 K
MAC address table additional information
Shared MAC address array for unicast and multicast (1:1 ratio)
ACL Table
216
Number of Vlan Interfaces (IP)
16
CPU Clock
800 MHz
Flash memory
32 MB
RAM memory
256 MB
Features
Enhanced Accessibility Features
IEEE 802.1D (STP), IEEE 802.1w (RSTP), IEEE 802.1 s (MSTP), IEEE 802.3 ad LACP, Virtual Cable Testing, DDM, LLDP, Loop Guard, ERPS (ITU-T G.8032)
Traffic control
IEEE 802.1Q, Port-based VLAN, Protocol-based VLAN, IP Subnet-based VLAN, Voice VLAN, MAC VLAN, Source/Destination IP LACP Algorithm (Load Balancing), GVRP, IEEE 802.1ad Vlan Stacking (QinQ), Flexible QinQ
Security
Layer 2 MAC filtering, BPDU Tunnel, Radius and Tacacs+ login authentication and authorization, Tacacs+ accounting/auditing, SSH v1/v2, DHCP/DCHPV6 Snooping, IP/IPv6 Source Guard, Port Security
QoS
IEEE 802.1p Priority Queues per Port (8 Queues), IEEE 802.1p Quering method, Trusted COS/TOS/IP Precedence/DSCP/Port number, Broadcast Storm Control, Rate Limiting, port based, Quering method - Strict priority/ Weighted Round Robin/ Weighted Deficit Round Robin Ścisły priorytet w Weighted Round Robin
L2/L3 multicast
Multicast VLAN, IGMP v1,v2, v3, IGMP Query, IGMP Snooping (v1/v2/v3), IGMP Snooping Fast Leave (v2,v3), IPv6 MLD v1/v2 Snooping
L3 IPv6
IPv4/IPv6 Dual Protocol Stack, IPv6 address
Management
Console port RS-232 (RJ45), GUI (Web), Telnet, SNMP v1/v2c/v3, TFTP/FTP, Configuration backup and restore, Multi-level CLI, DHCP Client/Relay/Server, DHCP relay per VLAN, DHCP option 43/60/82, DHCPv6 option 37/38, DHCPv6 Relay/Server, SNTP/NTP SP, sFlow, Port Mirroring for IP/TCP/UDP, RSPAN, IEEE 802.3ah EFM, IEEE 802.1ag CFM
MIB
RFC 1066 TCP/IP-based MIB, RFC1213, 1157 SNMPv2c/v3 MIB, RFC1493 bridge MIB, RFC 2674 bridge MIB extension, RFC1643 ethernet MIB, RFC1757 RMON group 1/2/3/9, RFC 2925 Remote Management MIB, RFC 2233 (rfc2233) - SMIv2 MIB
Electric
Power Supply
230 V AC
Maximum power consumption
? 20 W
| Áteresztő képesség | 42 |
| Gyártó | DCN |
| Menedzselhető | Van |
| Menedzselhetőség | Teljes |
| PoE (Power over Ethernet) | Nincs |
| Port típusa | 1Gb Réz |
| Portok száma | 28 |
| Rack-be szerelhető | Van |
| Routing / Switching | Layer 2 |
| SFP port | 4 |
| Switch típus | Fixed port |
| Switching kapacitás | 56 |
