Leírás és Paraméterek
Classification of switches
Layer
3
Connectivity
10/100/1000 Base-T (RJ45) ports
Ports 1/10G Base-X (SFP+)
40G Base-X (QSFP) ports
OOB management port (10/100/1000 Base-T RJ45)
1
Performance
Switching matrix
656 Gbps
Data transfer rate
488 Mpps
Packet Buffer
4 MB
JUMBO Frame
16 tys
Number of VLANs
4 tys
MAC address table
32 tys
Multicast support
4 tys
MAC address table additional information
Shared MAC address array for single and multicast broadcast (1:1 ratio)
ACL Table
2,7 tys (ingress), 1 tys (egress)
Number of Vlan Interfaces (IP)
1 tys
Reflection factor RL APC
16 tys
Additional information about the routing table
Shared routing table for IPv4 and IPv6 (4:1 ratio)
ARP table
1 tys
CPU Clock
dual core - 1,25 GHz
Number of Base-T ports (RJ45)
8
Available Base-T (RJ45) port speeds
10 ; 100 ; 1000
Number of Base-X ports (Optical)
26
Available Base-X (Optical) port speeds
1000; 10G; 40G
Ports 1/10G Base-X (SFP+)
24
40G Base-X (QSFP+) ports
2
Console port- RS-232 (RJ45)
Yes
OOB Management Port
Yes
Port USB
Yes
PoE available
No
Functionality of VSF
Yes
Functionality of PIM Router
Yes
Power supply
230 V + 48V DC
RPSU
No
Hot Swap PSU
No
RPS
Yes
Cooling
Active
Flash memory
160 MB
RAM memory
512 MB
Features
Enhanced Accessibility Features
IEEE 802.1D (STP), IEEE 802.1w (RSTP), IEEE 802.1s (MSTP), IEEE 802.3 ad LACP (128 groups per device/8 ports per group), Virtual Cable Testing, DDM, LLDP, Loop Guar
Traffic control
IEEE 802.1Q (4094 VLAN), Port-based VLAN, Protocol-based VLAN, IP Subnet-based VLAN, Voice VLAN, MAC VLAN, LACP Algorithm Source/Destination IP/MAC Address (Load Balancing), GVRP, IEEE 802.1ad Vlan Stacking (QinQ), Flexible QinQ
Security
Layer 2 MAC filtering, BPDU Tunnel, Radius and Tacacs+ login authentication and authorization, Tacacs+ accounting/auditing, SSH v1/v2, DHCP/DCHPV6 Snooping, IP/IPv6 Source Guard, Port Security
QoS
IEEE 802.1p Priority Queues per Port (8 Queues), IEEE 802.1p Quering method, Trusted COS/TOS/IP Precedence/DSCP/Port, Broadcast Storm Control, Rate Limiting, port based, Quering method - SP/DWRR/SDWRR
L2/L3 multicast
Multicast VLAN, IGMP Query, IGMP Snooping (v1/v2/v3), IGMP Snooping Fast Leave (v2,v3), PIM-DM/SM/SSM, anycast RP, IPv6 MLD v1/v2 Snooping
Routing
RIP v1/v2, RIPng, OSPF v2/v3, IPv6 Static Route, BGP4+
L3 IPv6
IPv4/IPv6 Dual Protocol Stack, IPv6 address, IPv6 Tunneling
Management
Console Port (CLI), RJ45 Management Port, USB2.0, GUI, Telnet, SNMP, TFTP/FTP, Configuration Backup and Restore, Multi-Level CLI, DHCP Client/Relay/Server, DHCP Relay per VLAN, DHCP Option 43/60/82, DHCPv6 Option 37/38, DHCPv6 Relay/Server, NTP, Port Mirroring for IP/TCP/UDP, RSPAN, OAM EFM/CFM
MIB
RFC1066 - TCP/IP-based MIB, RFC1213, 1157 - SNMPv2c/v3 MIB, RFC1493 - bridge MIB, RFC2674 - bridge MIB extension, RFC1643 - ethernet MIB, RFC1757 - RMON group 1,2,3,9, RFC2925 - remote MIB management, RFC2233 - SMIv2 MIB database
Electric
Power Supply
230 V AC
Redundant power supply
48 V DC, RPS
Maximum power consumption
? 85 W
| Áteresztő képesség | 488 |
| Gyártó | DCN |
| Menedzselhető | Van |
| Menedzselhetőség | Teljes |
| PoE (Power over Ethernet) | Nincs |
| Port típusa | 1Gb Réz |
| Portok száma | 34 |
| Rack-be szerelhető | Van |
| Routing / Switching | Layer 3 Advanced |
| SFP port | 26 |
| Switch típus | Modular |
| Switching kapacitás | 656 |
