Leírás és Paraméterek
| Product | 1960 24G 2XGT 2SFP+ |
| Part Number | JL806A |
| Switch Type | Fixed Port |
| Network OS | Aruba Instant On |
| Routing / Switching | Layer 2 Only |
| Management | Smart Managed |
| Included Accessories | |
| Included Accessories | N/A |
| Physical Properties | |
| Dimensions | 17.42(w) x 13.8(d) x 1.73(h) in (44.25 x 35.05 x 4.4 cm) (1U height) |
| Weight | 8.7 lb (3.9 kg) |
| Port Types | |
| LAN Ports | 24 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T) |
| Dual Personality Ports | N/A |
| 1/2.5/5/10GbE | N/A |
| SFP Ports | N/A |
| SFP+ Ports | 2 10GbE SFP+ ports |
| SFP28 Ports | N/A |
| SFP56 Ports | N/A |
| XFP Ports | N/A |
| X2 Ports | N/A |
| CX4 Ports | N/A |
| 10GBASE-T Ports | 2 10GBASE-T ports |
| QSFP+ Ports | N/A |
| QSFP28 Ports | N/A |
| QSFP56 Ports | N/A |
| QSFP-DD Ports | N/A |
| Module Slots | N/A |
| Console Port | N/A |
| Power Supplies | |
| Power supply slots | Internal power supply |
| Power supply requirements | N/A |
| Memory and Processor | |
| Memory and Processor | Single-Core ARM v7 Cortex-A9 @800MHz |
| Gigabit Module | N/A |
| 10Gb Module | N/A |
| Management Module | N/A |
| Fabric Module | N/A |
| I/O Module | N/A |
| Mounting | |
| Mounting | Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included) |
| Performance | |
| 100 Mb Latency | < 4.4 µs |
| 1000 Mb Latency | < 2.2 µs |
| 10 Gbps Latency | < 1.1 µs |
| 40 Gbps Latency | N/A |
| Throughput | up to 95.5 Mpps |
| Switching Capacity | 128 Gbps |
| Switch Fabric Speed | N/A |
| Routing Table Size | 32 IPv4/IPv6 |
| MAC Address Table Size | 16000 entries |
| MACsec Capable Hardware | N/A |
| MACsec Software Support | N/A |
| MACsec with EAP-TLS | N/A |
| MACsec Capable Uplink Ports | N/A |
| Electrical Characteristics | |
| Description | N/A |
| Voltage | 100-240 VAC |
| Current | 0.6A/0.2A |
| Gyártó | HP HEWLETT PACKARD |
