| Dimensions |
O415 x 303 mm (O16.34 x 11.93")
|
| Weight |
Without Mount: 1.3 kg (2.87 lb)
With Mount: 1.8 kg (3.97 lb)
|
| Enclosure Characteristics |
Aluminum / UV Stabilized Polycarbonate
|
| Processor |
Quad-Core ARM Cortex A7
|
| Memory |
256 MB DDR3
|
| Networking Interface |
10/100/1000 Mbps Ethernet RJ45
|
| RF Connections |
Internal
|
| Max. Power Consumption |
11W
|
| Power Method |
Passive PoE (Pairs 4, 5+; 7, 8-)
|
| Power Supply |
24VDC, 0.5A Gigabit PoE Adapter
|
| Supported Voltage Range |
22 to 26VDC
|
| ESD/EMP Protection |
Air/Contact: ± 24kV
|
| Operating Temperature |
-40 to 60° C (-40 to 140° F)
|
| Operating Humidity |
5 - 95% Noncondensing
|
| Certifications |
FCC, IC, CE
|
| Power |
Flashing White: Bootup in Progress
White: System Ready, Ubiquiti® Internet Service Provider (UISP™) Not Configured, Not Connected
Flashing Blue: System Ready, UISP Configured, but Cannot Connect
Blue: System Ready, UISP Configured and Connected
|
| Ethernet |
Flashing Blue: Ethernet Traffic Detected
|
| 5G |
Blue: Active Connection
|
| 60G |
Blue: Active Connection
|
| OS |
airOS®
|
| Operating Modes |
PtP
|
| Ubiquiti Specific Features |
Integrated 60 GHz and 5 GHz Radios, Discovery Protocol
|
| Security |
WPA2 AES Only
|
| Dashboard |
Yes
|
| Wireless Settings |
Yes
|
| Network Settings |
Yes
|
| System |
Yes
|
| Services |
UISP, Ping Watchdog, Web Server, SSH Server, NTP Client, System Log, Device Discovery
|
| Tools |
Antenna Alignment Tool, Discovery Utility, Traceroute, Speed Test
|
| Minimum Software Requirements |
Any Modern Web Browser
|
| Operating Frequency* |
| US/CA |
U-NII-1 |
5150 - 5250 MHz |
| U-NII-2A |
5250 - 5350 MHz |
| U-NII-2C |
5470 - 5725 MHz |
| U-NII-3 |
5725 - 5850 MHz |
| 57,000 - 66,000 MHz |
| Worldwide |
5150 - 5875 MHz
57,000 - 66,000 MHz |
* Depends on regulatory region.
|
| Max. Conducted TX Power |
25 dBm (5 GHz)
|
| Channel Bandwidth |
| 60 GHz |
2160 MHz |
| 5 GHz |
20/40/80 MHz |
|
| Management Radio |
| US/CA |
2412 - 2462 MHz |
| Worldwide |
2412 - 2472 MHz |
|
| Antenna Gain |
| 60 GHz |
38 dBi |
| 5 GHz |
11 dBi |
|
| 5 GHz TX Specifications |
| Data Rate |
Avg Power
(dBm) |
Tolerance
(dB) |
| 1x BPSK (1⁄2) |
25 |
±2 |
| 2x QPSK (1⁄2) |
25 |
±2 |
| 2x QPSK (3⁄4) |
25 |
±2 |
| 4x 16QAM (1⁄2) |
25 |
±2 |
| 4x 16QAM (3⁄4) |
25 |
±2 |
| 6x 64QAM (2⁄3) |
24 |
±2 |
| 6x 64QAM (3⁄4) |
22 |
±2 |
| 6x 64QAM (5⁄6) |
22 |
±2 |
| 8x 256QAM (3⁄4) |
21 |
±2 |
| 8x 256QAM (5⁄6) |
21 |
±2 |
|
| 5 GHz RX Specifications |
| Data Rate |
|
| Frekvencia |
60GHz |
| Gyártó |
UBIQUITI |
| Hatótávolság |
2km |
| Kültéri kivitel |
igen |
